Data Fields | |
| struct doca_pe * | pe |
| struct doca_dev * | dev |
| struct doca_devemu_pci_dev * | nvme_dev |
| uint16_t | sq_depth |
| struct doca_mmap * | host_sq_mmap |
| uintptr_t | host_sq_address |
| struct doca_devemu_pci_db_completion * | db_comp |
| uint32_t | sq_id |
| struct nvmf_doca_io * | io |
| struct spdk_nvmf_transport * | transport |
| void * | ctx |
Detailed Description
Definition at line 2403 of file nvmf_doca_io.c.
Field Documentation
◆ ctx
| void* nvmf_doca_sq_create_attr::ctx |
Opaque structure that can be set by user
Definition at line 2414 of file nvmf_doca_io.c.
◆ db_comp
| struct doca_devemu_pci_db_completion* nvmf_doca_sq_create_attr::db_comp |
DB completion context used by DPA to poll for DBs
Definition at line 2410 of file nvmf_doca_io.c.
◆ dev
| struct doca_dev* nvmf_doca_sq_create_attr::dev |
A doca device representing the emulation manager
Definition at line 2405 of file nvmf_doca_io.c.
◆ host_sq_address
| uintptr_t nvmf_doca_sq_create_attr::host_sq_address |
I/O address of the CQ on the Host
Definition at line 2409 of file nvmf_doca_io.c.
◆ host_sq_mmap
| struct doca_mmap* nvmf_doca_sq_create_attr::host_sq_mmap |
An mmap granting access to the Host CQ memory
Definition at line 2408 of file nvmf_doca_io.c.
◆ io
| struct nvmf_doca_io* nvmf_doca_sq_create_attr::io |
The IO that the SQ is added to
Definition at line 2412 of file nvmf_doca_io.c.
◆ nvme_dev
| struct doca_devemu_pci_dev* nvmf_doca_sq_create_attr::nvme_dev |
The emulated NVMe device used for creating the CQ DB
Definition at line 2406 of file nvmf_doca_io.c.
◆ pe
| struct doca_pe* nvmf_doca_sq_create_attr::pe |
Progress engine to be used by DMA context
Definition at line 2404 of file nvmf_doca_io.c.
◆ sq_depth
| uint16_t nvmf_doca_sq_create_attr::sq_depth |
The log of the CQ number of elements
Definition at line 2407 of file nvmf_doca_io.c.
◆ sq_id
| uint32_t nvmf_doca_sq_create_attr::sq_id |
The NVMe CQ ID that is associated with this IO
Definition at line 2411 of file nvmf_doca_io.c.
◆ transport
| struct spdk_nvmf_transport* nvmf_doca_sq_create_attr::transport |
The doca transport includes this SQ
Definition at line 2413 of file nvmf_doca_io.c.
The documentation for this struct was generated from the following file:
- applications/nvme_emulation/host/nvmf_doca_io.c
