doca flow packet format More...
#include <doca_flow.h>
Data Fields | |
| struct doca_flow_header_eth | eth |
| uint16_t | l2_valid_headers |
| struct doca_flow_header_eth_vlan | eth_vlan [DOCA_FLOW_VLAN_MAX] |
| enum doca_flow_l3_type | l3_type |
| union { | |
| struct doca_flow_header_ip4 ip4 | |
| struct doca_flow_header_ip6 ip6 | |
| }; | |
| enum doca_flow_l4_type_ext | l4_type_ext |
| union { | |
| struct doca_flow_header_icmp icmp | |
| struct doca_flow_header_udp udp | |
| struct doca_flow_header_tcp tcp | |
| struct doca_flow_header_l4_port transport | |
| struct doca_flow_header_roce_v2 roce_v2 | |
| }; | |
Detailed Description
doca flow packet format
Definition at line 439 of file doca_flow.h.
Field Documentation
◆
| union { ... } |
◆
| union { ... } |
◆ eth
| struct doca_flow_header_eth doca_flow_header_format::eth |
ether head
Definition at line 396 of file doca_flow.h.
◆ eth_vlan
| struct doca_flow_header_eth_vlan doca_flow_header_format::eth_vlan[DOCA_FLOW_VLAN_MAX] |
vlan header array
Definition at line 442 of file doca_flow.h.
◆ icmp
| struct doca_flow_header_icmp doca_flow_header_format::icmp |
icmp header
Definition at line 442 of file doca_flow.h.
◆ ip4
| struct doca_flow_header_ip4 doca_flow_header_format::ip4 |
ipv4 head
Definition at line 442 of file doca_flow.h.
◆ ip6
| struct doca_flow_header_ip6 doca_flow_header_format::ip6 |
ipv6 head
Definition at line 442 of file doca_flow.h.
◆ l2_valid_headers
| uint16_t doca_flow_header_format::l2_valid_headers |
indicate which headers are valid
Definition at line 442 of file doca_flow.h.
◆ l3_type
| enum doca_flow_l3_type doca_flow_header_format::l3_type |
layer 3 protocol type
Definition at line 442 of file doca_flow.h.
◆ l4_type_ext
| enum doca_flow_l4_type_ext doca_flow_header_format::l4_type_ext |
l4 layer extend type
Definition at line 442 of file doca_flow.h.
◆ roce_v2
| struct doca_flow_header_roce_v2 doca_flow_header_format::roce_v2 |
ROCEv2 header
Definition at line 442 of file doca_flow.h.
◆ tcp
| struct doca_flow_header_tcp doca_flow_header_format::tcp |
tcp header
Definition at line 442 of file doca_flow.h.
◆ transport
| struct doca_flow_header_l4_port doca_flow_header_format::transport |
transport layer source and destination port
Definition at line 442 of file doca_flow.h.
◆ udp
| struct doca_flow_header_udp doca_flow_header_format::udp |
udp header
Definition at line 442 of file doca_flow.h.
The documentation for this struct was generated from the following file:
- include/doca_flow.h
