doca flow tunnel information More...
#include <doca_flow_net.h>
Data Fields | |
| enum doca_flow_tun_type | type |
| union { | |
| struct { | |
| enum doca_flow_tun_ext_vxlan_type vxlan_type | |
| union { | |
| struct { | |
| uint8_t vxlan_gpe_flags | |
| uint8_t vxlan_gpe_next_protocol | |
| } | |
| struct { | |
| doca_be16_t vxlan_gbp_group_policy_id | |
| } | |
| } | |
| doca_be32_t vxlan_tun_id | |
| uint8_t vxlan_tun_rsvd1 | |
| } | |
| struct { | |
| enum doca_flow_tun_ext_gre_type gre_type | |
| doca_be16_t protocol | |
| union { | |
| struct { | |
| bool key_present | |
| doca_be32_t gre_key | |
| } | |
| struct { | |
| doca_be32_t nvgre_vs_id | |
| uint8_t nvgre_flow_id | |
| } | |
| } | |
| } | |
| struct { | |
| doca_be32_t gtp_teid | |
| uint8_t gtp_next_ext_hdr_type | |
| uint8_t gtp_ext_psc_qfi | |
| } | |
| struct { | |
| doca_be32_t esp_spi | |
| doca_be32_t esp_sn | |
| } | |
| struct { | |
| struct doca_flow_header_mpls mpls [DOCA_FLOW_MPLS_LABELS_MAX] | |
| } | |
| struct { | |
| struct doca_flow_header_geneve geneve | |
| union doca_flow_geneve_option geneve_options [DOCA_FLOW_GENEVE_OPT_LEN_MAX] | |
| } | |
| struct { | |
| struct doca_flow_header_psp psp | |
| } | |
| }; | |
Detailed Description
doca flow tunnel information
Definition at line 470 of file doca_flow_net.h.
Field Documentation
◆
| union { ... } |
◆ esp_sn
| doca_be32_t doca_flow_tun::esp_sn |
ipsec sequence number
Definition at line 527 of file doca_flow_net.h.
◆ esp_spi
| doca_be32_t doca_flow_tun::esp_spi |
ipsec session parameter index
Definition at line 525 of file doca_flow_net.h.
◆ geneve
| struct doca_flow_header_geneve doca_flow_tun::geneve |
geneve header
Definition at line 527 of file doca_flow_net.h.
◆ geneve_options
| union doca_flow_geneve_option doca_flow_tun::geneve_options[DOCA_FLOW_GENEVE_OPT_LEN_MAX] |
geneve options as array of doca_be32_t
Definition at line 527 of file doca_flow_net.h.
◆ gre_key
| doca_be32_t doca_flow_tun::gre_key |
gre key
Definition at line 503 of file doca_flow_net.h.
◆ gre_type
| enum doca_flow_tun_ext_gre_type doca_flow_tun::gre_type |
Definition at line 485 of file doca_flow_net.h.
◆ gtp_ext_psc_qfi
| uint8_t doca_flow_tun::gtp_ext_psc_qfi |
gtp PSC extension: QoS flow identifier
Definition at line 520 of file doca_flow_net.h.
◆ gtp_next_ext_hdr_type
| uint8_t doca_flow_tun::gtp_next_ext_hdr_type |
gtp next extension header type
Definition at line 518 of file doca_flow_net.h.
◆ gtp_teid
| doca_be32_t doca_flow_tun::gtp_teid |
gtp teid
Definition at line 516 of file doca_flow_net.h.
◆ key_present
| bool doca_flow_tun::key_present |
gre key is present
Definition at line 501 of file doca_flow_net.h.
◆ mpls
| struct doca_flow_header_mpls doca_flow_tun::mpls[DOCA_FLOW_MPLS_LABELS_MAX] |
mpls labels
Definition at line 527 of file doca_flow_net.h.
◆ nvgre_flow_id
| uint8_t doca_flow_tun::nvgre_flow_id |
nvgre flow id.
Definition at line 509 of file doca_flow_net.h.
◆ nvgre_vs_id
| doca_be32_t doca_flow_tun::nvgre_vs_id |
nvgre virtual subnet id(24) + reserved (8).
Definition at line 507 of file doca_flow_net.h.
◆ protocol
| doca_be16_t doca_flow_tun::protocol |
next protocol
Definition at line 497 of file doca_flow_net.h.
◆ psp
| struct doca_flow_header_psp doca_flow_tun::psp |
Definition at line 527 of file doca_flow_net.h.
◆ type
| enum doca_flow_tun_type doca_flow_tun::type |
tunnel type
Definition at line 415 of file doca_flow_net.h.
◆ vxlan_gbp_group_policy_id
| doca_be16_t doca_flow_tun::vxlan_gbp_group_policy_id |
vxlan gbp group policy id
Definition at line 485 of file doca_flow_net.h.
◆ vxlan_gpe_flags
| uint8_t doca_flow_tun::vxlan_gpe_flags |
vxlan gpe flags.
Definition at line 479 of file doca_flow_net.h.
◆ vxlan_gpe_next_protocol
| uint8_t doca_flow_tun::vxlan_gpe_next_protocol |
vxlan gpe next protocol
Definition at line 481 of file doca_flow_net.h.
◆ vxlan_tun_id
| doca_be32_t doca_flow_tun::vxlan_tun_id |
vxlan vni(24).
Definition at line 489 of file doca_flow_net.h.
◆ vxlan_tun_rsvd1
| uint8_t doca_flow_tun::vxlan_tun_rsvd1 |
vxlan last reserved byte.
Definition at line 491 of file doca_flow_net.h.
◆ vxlan_type
| enum doca_flow_tun_ext_vxlan_type doca_flow_tun::vxlan_type |
vxlan ext-type, standard, gpe, gbp
Definition at line 415 of file doca_flow_net.h.
The documentation for this struct was generated from the following file:
- include/doca_flow_net.h
